1.2 1.3 1.5GHz Anti Drone Shield Jamming Module for GPSL1 GPSL2 Glonass
ELUFA develops this Mini size drone jamming module as customer reflects their need of smaller size and light weight for jammer module, especially when the jammer module is used in the portable drone jammer such as anti drone gun, man pack drone Jammer and movable drone signal jammer. We also offer the 5W 10W 20W 30W 40W 50W 100W signal jammer module for other frequency of anti drone, also the phone jamming, WiFi jamming and GPS jamming.
Anti Drone Shield Jamming Module SpecificationÂ
| No. | Item | Data | Unit | Notes |
| 1 | Frequency | Customized | MHZ | |
| 2 | Work Temperature | -40~+65 | ℃ | |
| 3 | Max Output Power | 10 | W | |
| 4 | Work Voltage | 24/28/32 | V | |
| 5 | Max Gain | 40 | dB | |
| 6 | Flatness | ±3 | dB | |
| 7 | Max Current | 0.9 | A | |
| 8 | Output VSWR | ≤1.5 | ||
| 9 | Output Connector | SMA/F 50Ω | customized | |
| 10 | Power Amplifier Efficiency | 43 | when Max Output | |
| 11 | Switch Control | high low level current |
V | 0V off /0.6 on |
| 12 | Size | 97*43*17 | mm | |
| 13 | Weight | 0.102 | Kg |
